When filling the tank, the fuel passes through the vent pipe. Degassing passes through the vent pipe and unlike a standard fitting, the fuel instead of being discharged directly out through the vent, flows directly back into the tank.When the tank is full, it creates a back pressure.

The fuelling nozzle automatically stops the flow before any fuel spillage occurs therefore preventing any overspill from the vent or the filler.



ECONAB Diesel deck entry

ECDI03

Diameter of the fuelling pipe 50 mm


Diameter of vent pipe

16 mm


Hole diameter

65 mm

Integrated anti-theft grid

ECONAB Diesel deck entry

Made entirely of aluminium
Anodised surface treatment
Fixation with three screws to 120 °
Grooved hose connection Ø16 mm
Filling tube Ø 38 mm
depending on the model
Flange Ø 94 mm
Filler width Ø 65 mm
Filler height 150 mm
Exceeds the deck 8 mm
Deck thickness max 45 mm
Integrated anti-theft grid
Ground terminal Serial number

Optional fittings for vent pipe Ø 19 mm



ECDI05

Diameter of the fuelling pipe 50 mm


Diameter of vent pipe

16 mm


Hole diameter

65 mm

Deck fitting key

Made entirely of aluminium
Anodised surface treatment
Fixation with three screws to 120 °
Grooved hose connection Ø16 mm
Filling tube Ø 50 mm
depending on the model
Flange Ø 94 mm
Filler width Ø 65 mm
Filler height 150 mm
Exceeds the deck 8 mm
Deck thickness max 45 mm
Integrated anti-theft grid
Ground terminal Serial number

Optional fittings for vent pipe Ø 19 mm
